Features:
1. The use of high-quality PCB materials, quality assurance, greatly improving the service life of the product
2. LCD screen layout is reasonable, the font is large and full of rounded, professional power supply LCD screen, you want the function it has!
3. Built-in buzzer, key prompts, alarm prompts, safer and more assured use of the product
4. Upgraded plug-in terminals, easy to disassemble and replace.
5. The product has a wide range of applications, with MPPT function, support for MPPT solar charging, can be connected to the external temperature probe to support over-temperature protection.
Product parameters
Product nameDC buck-boost power supply
Model：XY-SK130
Input voltage：6-36.00V
Output voltage：0.0-36.00V
Output current：0-7.000A
Accuracy of voltage：+0.5%+1 word
Power output：150W
Accuracy of current：士0.5%+3 word
Resolution of voltage：0.01V
Resolution of current：0.001A
Storage data group：10 groups
Number of buttons：5
Screen size：Over 1.8-inch LCD with a viewable area of 38*29mm
Buzzer：YES
Soft start：YES
Efficiency of conversion：About 88%
Output ripple typical value:vpp-150mv
MPPT function：Support MPPT solar charging
Protection mechanism
Anti-reverse: YES
Anti-backflow: YES
under-voltage (LUP): (Adjustable 5.5-36V, default 5.5V)
over-voltage (OUP): (Adjustable from 0 to 38V, default is 38V)
over-current (OCP): (Adjustable from 0 to 7.2A, default 7.2A)
over-power (OPP): (Adjustable from 0 to 180W, default is 160W)
over-temp (OTP): Adjustable from 0 to 110℃, default is 95 ℃
over-time out (OHP): 1 minute-99 hours 59 minutes, off by default over-capacity (OAH): 0-9999Ah, off by default over-energy (OPH): 0-4200KWh, off by default
Packing list:
1 * Stabilized power supply
1 * Instruction manual
