3-Channel 1080P Dash Cam: Front, Interior & Rear Triple Recording with WiFi & Reversing Camera | 24/7 Parking Guard
Dash Cam: More than just recording—it’s all-round peace of mind
Many drivers often encounter blind spots, difficulties when reversing and poor visibility at night whilst on the road. This triple-camera dash cam solves all these issues at once, providing you with ultimate safety and convenience.
HD Triple Cameras, Eliminating Blind Spots
Front camera (170° ultra-wide angle) + Interior camera (120° wide angle) + Rear camera (120° wide angle): Simultaneous recording of three views – front, interior and rear. Whether preventing staged accidents, monitoring vehicle conditions or capturing scenery along the way, it provides a comprehensive, true-to-life view with no blind spots.
1080P HD Dual Recording and Split-Screen Display
Utilising advanced image processing algorithms and an F/2.0 large aperture, it delivers natural colours and rich detail. With support for three-screen simultaneous display, you can keep track of rear and interior activity at all times whilst driving.
Reversing Camera: Solves Parking Challenges
Paired with a dedicated rear-view camera, the DVR automatically switches to full-screen rear-view display when reverse gear is engaged, clearly showing the area behind the vehicle. Guideline assistance aids with parking manoeuvres, effectively minimising the risk of scrapes and bumps.
WiFi Mobile Connectivity: Real-time Playback with Zero Data Usage
Equipped with a built-in 2.4GHz WiFi module, connecting to the dashcam via the mobile app allows you to preview footage in real time, download video files and configure device settings without using your mobile data. Whether resolving accident disputes or sharing travel footage, everything can be managed with a single tap on your phone.
24-hour parking surveillance, round-the-clock protection for your vehicle
Optional smart voltage-reduction cable enables 24-hour parking surveillance. When the vehicle is switched off, the dashcam enters a low-power monitoring mode; should it detect vibrations or changes in the scene, it automatically records and saves the footage. The voltage-reduction cable features low-voltage power-off protection to prevent battery drain, ensuring round-the-clock safety for your vehicle.
G-sensor and loop recording ensure no frames are missed in critical moments
The built-in G-sensor automatically locks and saves the current video clip separately in the event of emergency braking or a collision, preventing it from being overwritten by the loop recording. Combined with intelligent loop recording technology, the system automatically overwrites the oldest standard video clips once the memory is full, eliminating the need for manual clearing and offering greater peace of mind on long journeys.
Easy Installation and Multi-Language Support
The main unit is secured via a bracket slot and snap-fit mechanism, with both 3M adhesive pads and screws provided for installation. The rear-view camera cable is routed along the edge of the headliner trim. The interface supports multiple languages including Russian, Japanese, French, Italian, German, English and Chinese, making it easy for drivers worldwide to use.
📊 Specifications
Image Sensor Front: GC1054 / Interior: 0308 / Rear: OV09
Resolution Front: 1920×1080P / Interior: 640×480P / Rear: 640×480P
Frame Rate 30fps
Display 2.0-inch IPS HD screen
Viewing Angle Front 170° / Interior 120° / Rear 120°
Aperture F/2.0
Video Codec H.264
WiFi 2.4GHz, supports app connectivity
G-sensor Built-in three-axis gravity sensor, supports collision locking
Parking Monitoring Optional step-down cable for 24-hour time-lapse recording / vibration wake-up
Reversing Camera Supported, CVBS signal input
Storage TF card slot, supports up to 128GB (U3 or higher), memory card not included
Power Interface USB 2.0 / DC 5V 2A
Operating Temperature -20°C to +70°C
🎁 Packing List
C309 Main Unit × 1
Rear-view Camera (with installation cable) × 1
Mounting Bracket × 1
3M Adhesive Pad × 1
Car Charger (Cigarette Lighter to USB) × 1
USB power cable × 1
Screws × 2
User manual × 1
❓ Frequently Asked Questions (FAQ)
Q1: Does the C309 support both dual-lens and triple-lens configurations?
A: Yes. The standard version comes with a front-facing + interior dual-lens module as standard, whilst the rear-view lens is an optional accessory. Users may choose between the “Dual-Lens Version” or the “Front + Interior + Rear Triple-Lens Kit” according to their requirements.
Q2: Do I need to purchase additional accessories for parking surveillance?
A: Yes. To enable 24-hour parking surveillance, you must select the Smart Step-Down Cable to connect the dashcam to the vehicle’s constant power supply. The step-down cable features a built-in low-voltage protection module that automatically cuts off power when the battery voltage drops below 11.6V, preventing the battery from draining and the vehicle from failing to start.
Q3: How is the reversing camera triggered?
A: The reversing detection wire (red wire) for the rear camera must be connected to the positive terminal of the vehicle’s reversing light. When reverse gear is engaged, the reversing light is energised, triggering a signal, and the DVR will automatically display the rear view in full screen.
Q4: Does the Wi-Fi connection use mobile data?
A: No. The WiFi signal emitted by the dashcam is a local area network hotspot. Once your mobile phone connects, it operates via point-to-point communication; therefore, neither previewing nor downloading files will consume your SIM card data allowance.
⚠️ Important reminder: This product does not include a memory card. We recommend using a high-speed TF card with a U3/UHS-3 rating and a capacity of 64GB–128GB to ensure stable recording of 1080p footage from all three channels without frame drops.
