| Material | ABS plastic |
| Voltage | 5V1.5A |
| Chip | Hi3520D V200 |
| Operating System | LINUX operating system |
| Image codec | H.264 |
| Preview effort | 4 * AHD / TV / CVI-1080N @ 25fps |
| encoding capacity | 4 * AHD / TV / CVI-1080N @ 25fps |
| Decoding Capability / Playback | 4 * AHD / TV / CVI-1080N @ 25fps |
| Multi-Mode Input | Coaxial: 4 * 1080N. 4 * 720P. 4 * 960H Mixed: 2 * 720P Coaxial + 2 * 720P Network: 8 * 1080P. 12 * 960P. 4 * 1080P. 4 * 720P. 1 * 1080P |
| Video Input | 4-way BNC |
| Video Output | 1 CVBS. HDMI. (MAX1920 * 1080) |
| Network connector | RJ45 10M / 100M |
| Audio Input / Output | 4 RCA / 1 RCA |
| Coaxial UTC | Support |
| USB connector | 2 * USB port (support for mobile hard disk 4TB not included) |
| Hard disk connector | 1 * eSATA + 1 * USB combo (support 4TB) Support up to 128G (U disk video) |
| TF card | support (up to 128GCIass10 not included) |
| Wireless Interface | 3G WIFI (extended by usb) |
| Operating temperature | 0 ° - + 55 ° 20 working humidity: 10% -90% |
| Atmospheric pressure | 86KPA-106KPA |
| Product Size | 12.2 * 9.7 * 3.2 |
| Packing size | 13.8 * 11.3 * 9.3 |
| product weight | 134g |
| Product gross weight | 394g |
